Here is a highly effective way to alert you to any unauthorized use, theft or vandalism of important devices, as well as unauthorized exits and entries. The combination of alarm and super bright flashing LEDs offers excellent protection for an array of circumstances as they draw attention in a hurry. Select-Alert allows you to choose its function and can be used as a cabinet alarm, door/exit alarm, flashing light linked with a push button/switch, tornado siren, burglar alarm or an alert for many types of emergency situations.
Unit of Measure

Dimensions

Overall Width

 N/A 3.25 in83 mm

Overall Height

 N/A 4.83 in123 mm

Specifications

Alarm Depth

 N/A 1.58 in40 mm

Surface Mount Depth

 N/A 2.73 in69 mm
Alarm and Strobe Timing1 N/A 15 s30 s60 sContinuous

Low Battery Warning

 N/A LEDs flash once every 30 seconds

Form C Dry Contacts

 N/A 0-30 Volts (V) AC/DC, 1 Ampere (A) Contacts reset after longest alarm setting

Key Switch

 N/A Alarm on: normally closed

Alarm Circuit

 N/A Open circuit (close goes to alarm)

Alarm Tone

 N/A 32 selectable sounds

Working Temperature

 N/A -40 to 250 ºF-40 to 121 ºC

Color

 N/A White
Warranty2 N/A 3 y

Application

 N/A Theft Prevention

Operating Voltage

Internal Operating Direct Current (DC) Voltage (Not Included)

 N/A 9 V

Remote Power Operating Direct Current (DC) Voltage

 N/A 12 to 24 V

Power Consumption

Stand By Power Consumption

 N/A 50 mA

Power Consumption for Low Volume Siren

 N/A 85 mA

Power Consumption for High Volume Siren

 N/A 90 mA

Power Consumption (Strobe)

 N/A 25 mA

Siren Volume

Siren Volume (Low) at 1 Feet (ft)

 N/A 85 dB

Siren Volume (High) at 1 Feet (ft)

 N/A 100 dB

How It Works

How It Works

 N/A When installed as a cabinet or door alarm, with the optional reed switch and magnet, Select-Alert emits an ear piercing siren and the LEDs flash when the protected unit is opened. The alarm and strobe have independent timing choices of: 15 seconds, 30 seconds, 60 seconds or continuous and the alarm has an option of 32 tones. Can be powered by a 9 VDC battery or external 12 - 24 volts. Flush or surface mount Select-Alert is available in amber, green, blue, red or white.

Key Features

General Information

 N/A
  • Alerts to any unauthorized use, theft or vandalism of important devices, as well as unauthorized exits and entries.
  • Alarm offers 32 tones.
  • Includes ten high intensity LEDs.
  • For indoor use only.

Construction

 N/A
  • Durable, polycarbonate construction.

Installation

 N/A
  • Includes a tamper switch which prevents it from being removed from a wall.
  • Typical working properties of polycarbonate are -40 to 250 ºF (-40 to 121 ºC).

Electronics

 N/A
  • May be set for a piercing 100 dB alarm or a softer 85 dB.
  • One Form "C" dry relay contact output.
  • Powered by a 9 V DC battery (not included) or external 12 - 24 volts.
  • Low battery indicator.

Options

 N/A
  • Can be used as a cabinet alarm, door alarm, link with push button/switch or as a burglar alarm.
  • Available with amber, green, blue, red or white lens.

Accessories

Accessories

 N/A KIT-71100A-W: Back Box Kit
KIT-H18075: Replacement Key for Select-Alert Alarm
KIT-E18151: Open Circuit Reed Switch and Magnet
KIT-SA505: Key Switch Mounting Bracket (Includes Key Switch)
EBAT-9 V DC: 9 Volt Battery
  • 1 Independent control for siren and strobe.
  • 2 Three year guarantee against breakage of polycarbonate in normal use (one year on electromechanical and electronic components)
